Maintenance
84
EMU41671
Inspecting propeller
EWM02681
You could be seriously injured if the en-
gine accidentally starts when you are
near the propeller. Before inspecting, re-
moving, or installing the propeller, move
the control lever to the neutral position,
turn the main switch to the “ ” (off) po-
sition, remove the key, and remove the
clip from the engine shut-off switch. Turn
off the battery cut-off switch if your boat
has one.
Do not use your hand to hold the propeller
when loosening or tightening the propeller
nut. Place a block of wood between the anti-
cavitation plate and the propeller to prevent
the propeller from turning.
Checkpoints
Check each of the propeller blades for ero-
sion from cavitation or ventilation, and oth-
er damage.
Check the propeller shaft for damage.
Check the splines for wear and damage.
Check for fish line tangled around the pro-
peller shaft.
EMU41992
Removing propeller
1. Straighten the cotter pin and pull it out
using a pair of pliers.
2. Remove the propeller nut, washer, and
spacer. WARNING! Do not use your
hand to hold the propeller when loos-
1. Propeller shaft
