Yamaha F30A - Page 122

POWR
Power unit
5-27 67C3K11
No.
Part name Q’ty Remarks
1 Oil seal 1
Not reusable
2Bolt 1
3Gasket 1
Not reusable
4 Cylinder head 1
5 Exhaust valve 3
6 Intake valve 3
7Camshaft 1
8O-ring 1
Not reusable
9O-ring 1
Not reusable
10 O-ring 1
Not reusable
11 Oil pump assembly 1
12 Bolt 4 M6 × 45 mm
13 Valve cotter 12
14 Valve spring retainer 6
15 Valve spring 6
16 Valve spring seat 6
17 Valve seal 6
Not reusable
S67C5067
