Yamaha F30A - Ptt Cylinder

67C3K11 7-46
1
2
3
4
5
6
7
8
9
PTT cylinder
No.
Part name Q’ty Remarks
1 Tilt ram assembly 1
2 Dust seal 1
Not reusable
3O-ring 1
Not reusable
4O-ring 1
Not reusable
5 Backup ring 1
6 Free piston assembly 1
7O-ring 1
Not reusable
8 Cylinder 1
S67C7087
7
1
6
8
LT
271
T
R
.
.
90 N
·
m (9.0 kgf
·
m, 66.4 ft
·
Ib)
T
R
.
.
61 N
·
m (6.1 kgf
·
m, 45.0 ft
·
Ib)
AA
3
4
5
2
PTT gear pump / PTT cylinder
