Yamaha F30A - Tiller Handle (H Model)

BRKT
Bracket unit
7-1 67C3K11
Tiller handle (H model)
No.
Part name Q’ty Remarks
1 Tiller handle assembly 1
2 Shift cable 1
3 Throttle cable 1
4 Clip 2
5Bolt 3 M6 × 25 mm
6 Retaining plate 1
7 Cable holder 1
8Grommet 1
9 Grommet 1 M model
10 Grommet 1 E and W model
11 Washer 2
12 Self-locking nut 2
S67C7001
1
9
6
3
5
5
12
11
12
11
2
4
4
10
8
7
T
R
.
.
10 N
·
m (1.0 kgf
·
m, 7.4 ft
·
Ib)
