Yamaha F30A - Friction Plate (H Model)

67C3K11 7-8
1
2
3
4
5
6
7
8
9
Friction plate (H model)
No.
Part name Q’ty Remarks
1Bolt 1 M5 × 20 mm
2 Steering lock shaft 1
3Bracket 1
4 Collar 1 Short
5 Washer 2
6 Self-locking nut 2
7 Washer 2
8 Steering lock lever 1
9 Friction piece 2
10 Collar 1 Long
11 Friction plate 1
12 Steering lock washer 1
13 Self-locking nut 1
14 Nut 1
15 Speedometer hose 1
16 Holder 1
17 Bolt 2 M6 × 12 mm
S67C7009
TOP
4
10
9.0 mm
(0.35 in)
3.7 mm
(0.15 in)
5.4 mm
(0.21 in)
8.0 mm
(0.31 in)
3
2
4
8
3
17
17
6
6
5
5
9
12
13
14
16
15
9
7
8
7
4
10
11
3
1
2
T
R
.
.
7 N
·
m (0.7 kgf
·
m, 5.2 ft
·
Ib)
572
LT
T
R
.
.
4 N
·
m (0.4 kgf
·
m, 3.0 ft
·
Ib)
T
R
.
.
8 N
·
m (0.8 kgf
·
m, 5.9 ft
·
Ib)
T
R
.
.
37 N
·
m (3.7 kgf
·
m, 27.3 ft
·
Ib)
Tiller handle (H model) / Friction plate (H model)
