Yamaha F60C - Exhaust Cover

POWR
Power unit
5-35
6C13G11
Exhaust cover
5
No. Part name Q’ty Remarks
1 Cooling water temperature sensor 1
2Gasket 1
Not reusable
3Bolt 1 M6
×
14 mm
4 Holder 1
5Bolt 1 M6
×
14 mm
6Plug 1 M14
×
12 mm
7Gasket 1
Not reusable
8Plug 1 M8
×
17 mm
9Gasket 1
Not reusable
10 Thermostat 1
11 Gasket 1
Not reusable
12 Thermostat cover 1
13 Bolt 12 M6
×
35 mm
14 Gasket 1
Not reusable
15 Exhaust cover 1
16 Grommet 1
17 Anode 1
