Yamaha F60C - Propeller Shaft Housing (F50, F60)

6C13G11
6-8
1
2
3
4
5
6
7
8
9
Propeller shaft housing (F50, F60)
6
No. Part name Q’ty Remarks
1 Shift plunger 1
2 Dog clutch 1
3Cross pin 1
4Spring 1
5 Shift slider 1
6Spring 1
7 Propeller shaft 1
8 Reverse gear 1
9 Reverse gear shim —
10 O-ring 1
Not reusable
11 Ball bearing 1
Not reusable
12 O-ring 2
Not reusable
13 Propeller shaft housing 1
14 Needle bearing 1
15 Oil seal 2
Not reusable
16 Bolt 2 M8
×
25 mm
17 Washer 1
Lower unit (F50, F60) / Propeller shaft housing (F50, F60)
