Yamaha F60C - Page 172

LOWR
Lower unit
6-29
6C13G11
6
No. Part name Q’ty Remarks
18 Stud bolt 4 X-transom model
19 Bolt 1 M8
×
185 mm/X-transom model
20 Dowel 2 X-transom model
21 Extension 1 X-transom model
22 Washer 4 X-transom model
23 Spring washer 4 X-transom model
24 Nut 4 X-transom model
