Yamaha F75B - Engine Stop Button; Main Switch

Components
20
EMU26001
Engine stop button
To open the ignition circuit and stop the en-
gine, push this button.
EMU26090
Main switch
The main switch controls the ignition system;
its operation is described below.
● “” (off)
With the main switch in the “” (off) posi-
tion, the electrical circuits are off, and the key
can be removed.
● “” (on)
With the main switch in the “” (on) position,
the electrical circuits are on, and the key can-
not be removed.
● “” (start)
With the main switch in the “” (start) po-
sition, the starter motor turns to start the en-
gine. When the key is released, it returns
automatically to the “” (on) position.
1. Cord
2. Clip
3. Engine shut-off switch
1. Cord
2. Clip
3. Engine shut-off switch
