2-3
GB
EMU00100
Neutral Throttle Lever
To open the throttle without shifting into
either Forward or Reverse, place the
remote control lever in the Neutral posi-
tion and lift the neutral throttle lever.
NOTE:
The neutral throttle lever will operate only
when the remote control lever is in Neu-
tral. The remote control lever will operate
only when the neutral throttle lever is in
the closed position.
1 Fully open
2 Fully closed
EMU00101
Main switch
The main switch controls the ignition sys-
tem; its operation is described below.
8 OFF
Electrical circuits switched off.
(The key can be removed.)
8 ON
Electrical circuits switched on.
(The key cannot be removed.)
8 START
Starter-motor will turn and start engine.
(When the key is released, it returns auto-
matically to “ON”.)
ON
STARTOFF
701045
701036
EMU00099
Neutral Interlock Trigger
To shift out of Neutral, the neutral inter-
lock trigger of the remote control lever
must first be pulled up.
67F-9-76-A0-2 4/1/02 4:02 PM Page 8
