2-8
GB
EMU01617
DIGITAL TACHOMETER
This gauge contains the tachometer, trim
meter, hour meter, low oil pressure warn-
ing indicator, and the overheat warning
indicator.
1 Tachometer
2 Trim meter
3 Hour meter
4 Low oil pressure warning indicator
5 Overheat warning indicator
6 Set button
7 Mode button
NOTE:
All segments of the display will light
momentarily after the main switch is
turned on and will return to normal there-
after.
001085
001058
EMU00136
Tachometer
This meter shows the engine speed.
67F-9-76-A0-2 4/1/02 4:02 PM Page 18
