GB
2-14
EMU00157
TILT SUPPORT LEVER
To keep the outboard motor in the tilted-
up position, lock the tilt support lever to
the clamp bracket.
EMU00163
TOP COWLING LOCK LEVERS
To remove the engine top cowling, pull
up the front and rear lock levers. Then lift
off the cowling. When replacing the cowl-
ing, check to be sure it fits properly in the
rubber seal. Then lock the cowling again
by moving the levers downward.
F1008B
F1009
EMU01146
FLUSHING DEVICE
This device 1 is used to clean the cooling
water passages of the motor using a gar-
den hose and tap water.
NOTE:
Refer to “Cleaning Cooling-water Pas-
sages” in Chapter 4 for instructions on
usage.
67F-9-76-A0-2 4/1/02 4:02 PM Page 30
