Yamaha F8F - Components; Component Identification Diagram; External Outboard Motor Components

Components
17
EMU46722
Components diagram
TIP:
* May not be exactly as shown; also may not be included as standard equipment on all models
(order from dealer).
F6DMH, F6DM, F8FMH, F8FE
1
8
9
10
2
3
5
6
7
12
11
4
1. Top cowling
2. Clamp bracket
3. Trim rod
4. Anode
5. Drain screw
6. Cooling water inlet
7. Propeller
8. Cowling lock lever
9. Idle hole
10.Anti-cavitation plate
11.Remote control box (side mount type)*
12.Fuel tank
