Yamaha F8F - Starting and Tilting Components

Components
24
EMU26015
Pull-type choke knob
Pull the choke knob to supply a rich fuel mix-
ture to the engine.
EMU26075
Manual starter handle
The manual starter handle is used to crank
and start the engine.
EMU26092
Main switch
The main switch controls the ignition system;
its operation is described below.
 “” (off)
With the main switch in the “ ” (off) posi-
tion, the electrical circuits are off, and the key
can be removed.
 “” (on)
With the main switch in the “ ” (on) position,
the electrical circuits are on, and the key can-
not be removed.
 “” (start)
With the main switch in the “ ” (start) po-
sition, the starter motor turns to start the en-
gine. When the key is released, it returns
automatically to the “ ” (on) position.
EMU26103
Power tilt switch
The power tilt system adjusts the outboard
motor angle in relation to the transom. Push-
ing the switch “ ” (up) tilts the outboard mo-
tor up. Pressing the switch “ ” (down) tilts
the outboard motor down. When the switch is
released, the outboard motor will stop in its
current position.
TIP:
For instructions on using the power tilt
switch, see pages 49 and 52.
1. Choke knob
1
ON
STARTOFF
ZMU01718
DN
UP
ZMU01720
