Instrument and control functions
4-4
4
EAUT1822
Speedometer unit
The speedometer unit is equipped with
a speedometer and an odometer. The
speedometer shows the riding speed.
The odometer shows the total distance
traveled.
EAU37053
Fuel gauge
The fuel gauge indicates the amount of
fuel in the fuel tank. The needle moves
towards “E” (Empty) as the fuel level
decreases. When the needle reaches
the red zone, approximately remain in
the fuel tank. If this occurs, refuel as
soon as possible.
TIP
The main switch must be turned to
“ON” for the fuel gauge to display an
accurate fuel level reading.
EAU1234R
Handlebar switches
Left
Right
1. Odometer
2. Speedometer
km h
1
2
3
4
2
1
1. Red zone
2. Fuel gauge
EF
N
21
1. Horn switch “ ”
2. Turn signal switch “ / ”
3. Dimmer switch “ / ”
1. Start switch
3
2
1
1
