Yamaha FINN - Brake Pedal; Fuel Tank Cap

Instrument and control functions
4-6
4
EAU12944
Brake pedal
The brake pedal is located on the right
side of the motorcycle. To apply the
rear brake, press down on the brake
pedal.
EAU37474
Fuel tank cap
To remove the fuel tank cap
1. Open the seat. (See page 4-8.)
2. Turn the fuel tank cap counter-
clockwise and pull it off.
To install the fuel tank cap
1. Insert the fuel tank cap into the
tank opening and turn it clockwise
until the “ ” marks on the cap
and tank cover are aligned.
2. Close the seat.
WARNING
EWA11092
Make sure that the fuel tank cap is
properly closed after filling fuel.
Leaking fuel is a fire hazard.
1. Brake pedal
1
1. Fuel tank cap
2. “ ” mark
1
2
