Periodic maintenance and adjustment
7-8
7
To install the cowling
Place the cowling in the original posi-
tion, and then install the screws.
EAUU2040
Panel A
To remove the panel
Remove the bolts and screws, and
then take the panel off.
To install the panel
Place the panel in the original position,
and then install the bolts and screws.
Panel B
To remove the panel
1. Open the seat. (See page 4-8.)
2. Remove the screws, and then pull
the panel by pulling it up.
To install the panel
1. Place the panel in the original po-
sition, and then install the screws.
2. Close the seat.
1. Cowling B
2. Screw
12
1. Panel A
2. Screw
3. Bolt
1
2
3
1. Screw
1
