Yamaha FINN - Page 46

Periodic maintenance and adjustment
7-11
7
5. If the engine oil is at or below the
minimum level mark, add oil.
6. Check the oil O-ring for damage.
Replace if necessary.
7. Install the oil filler cap.
To change the engine oil (and re-
place the filter)
1. Start the engine, warm it up for
several minutes, and then turn it
off.
2. Place an oil pan under the engine
to collect the used oil.
3. Remove the engine oil filler cap.
4. Remove the engine oil drain bolt
and gasket. Discard the used gas-
ket.
TIP
Skip steps 4–6 if the oil filter element is
not being replaced.
5. Remove the oil filter element cover
by removing the bolts.
6. Remove the used oil filter element
and O-rings. Replace with new
parts.
1. Engine oil filler cap
1. Dipstick
2. Maximum level mark
3. Minimum level mark
4. O-ring
1
ZAUV0288ZAUV0288ZAUV0288
2
3
1
4
1. Engine oil drain bolt
1
1. Bolt
2. Oil filter element cover
1. Oil filter element
2. O-ring
1
2
2
1
ZAUV0291
