Components
EMU2579W
Components diagram
TIP:
* May not be exactly as shown; also may not be included as standard equipment on all mod-
els (order from dealer).
F300A, FL300A, F350, LF350, F350A1, FL350A1
1
2
3
4
5
6
7
7
8
9
7
10
10
6
ZMU05813
1. Top cowling
2. Anti-cavitation plate
3. Propeller*
4. Cooling water inlet
5. Clamp bracket
6. Tilt support lever
7. Cowling lock lever(s)
8. Fuel filter/water separator
9. Flushing device
10. Power trim and tilt switch
