Operation
48
NOTICE
ECM00241
● Before tilting the outboard motor, stop
the engine by following the procedure
on page 44. Never tilt the outboard mo-
tor while the engine is running. Severe
damage from overheating can result.
● Do not tilt up the engine by pushing the
tiller handle (if equipped) because this
could break the handle.
EMU2797B
Procedure for tilting up (manual tilt
models)
1. Place the remote control lever / gear shift
lever in neutral.
2. Disconnect the fuel line from the out-
board motor.
3. Place the tilt lock lever (if equipped) in the
release/up position.
4. Pull up the shallow water lever (if
equipped).
5. Hold the rear of the top cowling with one
hand and tilt the engine up fully.
6. Push the tilt support knob into the clamp
bracket. Or the tilt support bar will turn to
the lock position automatically. NOTICE:
U60R76E0.book Page 48 Monday, April 26, 2010 3:39 PM
