8-1
ELECTRICAL COMPONENTS
ELECTRICAL COMPONENTS
(ONE LIGHTING COIL MODEL)
Top view and left side view
1 Pulser coil
2 Emergency signal light
3 Lighting coil
4 Oil pressure switch
5 Spark plug
6 Charge coil
7 CDI unit
8
Rectifier
9
Ignition coil
A
Short handle model
B
Long handle model
