5-21
POWER UNIT
REMOVING/INST
ALLING THE LEF
T SIDE ELECTRICAL COMPONENTS
1 (TWO
LIGHTING C
OILS MODEL)
Step
Job/Part
Q'ty
Remar
ks
1C
l
a
m
p
1
Not reusa
ble
2
Bolt (with washer)
2
3
Ignition coil
1
2 leads (Orange, Black)
4
Bolt (with washer)
1
5C
l
a
m
p
1
6C
l
a
m
p
1
Not reusa
ble
7
Bolt (with washer)
1
8
Rectifier/regulator
1
4 leads (Blac
k, Red, Green x 2
)
9
Bolt (with washer)
2
10
Bolt (with washer)
1
11
St
arte
r m
otor
bra
cke
t
1
For install
ation, rever
se the
remova
l
procedure.
