50
UPPER CASE
UPPER CASE
DIS
ASSE
MBLI
NG/ASS
EMBLI
NG T
HE UPP
ER CASE
Step
Job/Part
Q'ty
Remarks
1
Bo
lt (w
ith w
ash
er)
2
2
Upper side mount rubber
1
3
Bo
lt (w
ith w
ash
er)
42
4
Exhaust guide
1
5
Clip
1
6
Oil strai
ner
1
7
Oil seal
1
Not reusa
ble
8G
a
s
k
e
t
1
Not reusa
ble
9P
i
n
2
10
Hose
1
11
Screw
1
12
Plat
e
1
13
Dampe
r
1
Continued on next page.
