Yamaha FT8DEP Service Manual

36
PROPELLER SHAFT HOUSING ASS’Y
2. Install:
O
Oil seals
NOTE:
First, fully install the lower oil seal and then
the upper.
3. Install:
O
Ball bearing
NOTE:
Install the ball bearing with its manufactur-
er’s marks
a
facing towards the reverse
gear.
4. Install:
O
Reverse gear shim(s) 1
O
Reverse gear 2
Oil seal depth
a
:
4.5 - 5.0 mm (0.18 - 0.20 in)
Oil seal installer
1
:
(Needle bearing attachment)
N.A./90980-06614
Driver rod
2
:
YB-06071/90890-06604
Driver rod
1
:
YB-06071/90890-06606
Ball bearing attachment
2
:
YB-06015/90890-06632

Yamaha FT8DEP Specifications

General

Engine Type	4-stroke, SOHC
Power Output	8hp
Starting System	Manual
Gear Ratio	2.08:1
Propeller Shaft Horsepower	8hp
Fuel Induction System	Carburetor
Ignition System	CDI
Lubrication	Wet sump
Exhaust	Through propeller hub
Cooling	Water-cooled
Alternator Output	6A
Fuel Tank Capacity	12 litres
Full Throttle RPM Range	5000-6000 rpm
Fuel Type	Gasoline
Shaft Length	15 in
