NOTE:
8 When flushing the engine with the boat
in the water, tilting up the engine until it
is completely out of the water will
achieve better results.
8 Refer to cooling system flushing
instructions in “TRANSPORTING AND
STORING OUTBOARD MOTOR”.
EMU00409
MOTOR EXTERIOR
EMU00410
Cleaning the Outboard Motor
After use, wash the exterior of the out-
board with fresh water.
Flush the cooling system with fresh
water.
NOTE:
Refer to Flushing Cooling System instruc-
tions in “TRANSPORTING AND STORING
OUTBOARD MOTOR”.
EMU00412
Checking Painted Surface of Motor
Check the motor for scratches, nicks, or
flaking paint. Areas with damaged paint
are more likely to corrode. If necessary,
clean and paint the areas. A touch-up
paint is available from a Yamaha dealer.
Attachment size:
Inside diameter 1.0 inch (25.4 mm)
Pitch 1/12 inch (2.1 mm)
66M-9-77-A0-4b 3/5/03 10:54 AM Page 36
