GB
2-6
EMU01294
Throttle Friction Adjusting Knob
A friction device in the tiller handle pro-
vides resistance to movement of the
throttle grip. This is adjustable for opera-
tor preference.
When constant speed is desired, tighten
the adjusting knob to maintain the
desired throttle setting.
w
Do not overtighten the friction adjusting
knob. If there is too much resistance, it
may be difficult to move the throttle grip,
which could result in an accident.
EMU00067
Throttle Indicator
The fuel consumption curve on the throt-
tle indicator shows the relative amount of
fuel consumed for each throttle position.
Choose the setting that offers the best
performance and fuel economy for the
desired operation.
1 Throttle indicator
Resistance Knob
Increase Turn clockwise
Decrease Turn counterclockwise
66M-9-77-A0-2 3/5/03 9:38 AM Page 14
