Yamaha HTR-5140 User Manual

5
English
● 5-Channel Power Amplification
Minimum RMS Output Power
<0.04% THD, 20 Hz – 20 kHz>
Main: 60 W + 60 W (8 Ω)
Center:60 W (8 Ω)
Rear: 60 W + 60 W (8 Ω)
<0.07% THD, 1 kHz>
Main: 70 W + 70 W (8 Ω)
Center:70 W (8 Ω)
Rear: 70 W + 70 W (8 Ω)
● Digital Sound Field Processor
● Dolby Digital Decoder
● Dolby Pro Logic Surround Decoder
● CINEMA DSP: Theater-like Sound
Experience by the Combination of Dolby
Surround and YAMAHA DSP Technology
SUPPLIED ACCESSORIES........................................... 4
FEATURES .................................................................... 5
CAUTION ....................................................................... 6
● Introduction
FEATURES OF SOUND EFFECTS ............................... 7
CONTROLS AND THEIR FUNCTIONS ......................... 9
● Preparation
SPEAKER SETUP ....................................................... 14
CONNECTIONS........................................................... 16
ADJUSTMENTS
BEFORE USING THIS UNIT .................................. 23
● Basic Operation
BASIC OPERATIONS .................................................. 28
TUNING OPERATIONS ............................................... 32
SETTING THE SLEEP TIMER..................................... 37
● Information about DSP
USING THE DIGITAL SOUND FIELD
PROCESSOR (DSP) .............................................. 38
● Advanced Information
ADJUSTMENTS
IN THE “SET MENU” MODE................................... 44
● Remote Control Transmitter
REMOTE CONTROL TRANSMITTER ......................... 46
SETUP CODES ........................................................... 53
TROUBLESHOOTING ................................................. 54
SPECIFICATIONS ....................................................... 57
LIST OF MANUFACTURER’S CODES...................... 113
FEATURES
CONTENTS
● 6-Channel External Decoder Input for DTS
and other future formats
● Automatic Input Balance Control for
Dolby Pro Logic Surround
● Test Tone Generator for Easier Speaker
Balance Adjustment
● Speaker Output Mode Changing
Capability
● 40-Station Random Access Preset Tuning
● Automatic Preset Tuning
● Preset Station Shifting Capability
(Preset Editing)
● Video Signal Input/Output Capability
● SLEEP Timer
● Universal Remote Control
Transmitter with Preset Manufacturer
Codes
05HTR-5140-e/f-1 6/22/99, 2:04 PM5

Yamaha HTR-5140 Specifications

General

Type	AV receiver
Channels	5.1
Frequency Response	10 Hz - 100 kHz
Input Impedance	47 kΩ
Dimensions (W x H x D)	435 x 151 x 391mm
Weight	9.8kg
Surround Sound	Dolby Digital, DTS
Input Sensitivity	200 mV
Signal to Noise Ratio	100 dB
Signal-to-Noise Ratio	100 dB
Total Harmonic Distortion	0.06% (1kHz)
Input Sensitivity/Impedance	200 mV / 47 kΩ
Video Inputs/Outputs	3 Inputs, 1 Output
Audio Inputs/Outputs	4 Inputs, 1 Output
Digital Audio Inputs	Optical (2), Coaxial (1)
