57
SET MENU
ADVANCED
OPERATION
■ Audio settings G)AUDIO SET
Use to customize this units overall audio settings.
Muting type MUTE TYP.
Use to adjust how much the mute function reduces the
output volume.
Choices: FULL, –20dB
• Select FULL to completely halt all output of sound.
• Select –20dB to reduce the current volume by 20 dB.
Audio delay A.DELAY
Use to delay the sound output and synchronize it with the
video image. This may be necessary when using certain
LCD monitors or projectors.
Choices: 0 to 160 ms
Tone bypass TC.BYPASS
Use to select whether audio output bypasses tone control
circuitry when TREBLE and BASS (page 25) are set to
0 dB.
Choices: AUTO, OFF
• Select AUTO if you want signals to bypass tone
control circuitry to provide the purest signal possible.
• Select OFF if you do not want signals to bypass tone
control circuitry.
Use to reassign digital input/outputs and select the input
mode.
■ Input/output assignment
A)I/O ASSIGN
You can assign jacks according to the component to be
used if this unit’s initial settings do not correspond to your
needs. Change the following parameters to reassign the
respective jacks and effectively connect more
components.
Once the inputs have been reassigned, you can select the
corresponding component by using INPUT on the front
panel or the input selector buttons on the remote control.
For COMPONENT VIDEO jacks A (C.V[A]) and
B (C.V[B])
Choices: [A] DVD, DTV/CBL, V-AUX, VCR
[B] DVD, DTV/CBL, V-AUX, VCR
For DIGITAL INPUT jacks 1 (IN (1)) and
2 (IN (2))
Choices: (1) CD, MD/CD-R, DVD, DTV/CBL, V-AUX,
VCR
(2) CD, MD/CD-R, DVD, DTV/CBL, V-AUX,
VCR
For COAXIAL INPUT jack 3 (IN (3))
Choices: CD, MD/CD-R, DVD, DTV/CBL, V-AUX,
VCR
• You cannot select a specific item more than once for the same
type of jack.
• When you connect a component to both the COAXIAL and
OPTICAL jacks, priority is given to the input signals from the
COAXIAL jack.
2 INPUT MENU
Notes
