SPECIAL TOOLS
1-7
Piston base
YSST-604
(90890-01067)
This tool is used to support the piston.
Small screw driver
YSST-609
This tool is used to adjust throttle screw/retract tim-
ing chain tensioner.
Scraper
YSST-612
This tool is used to scrap the sealant from crank-
case surface.
Cup-A
YSST-620-A
This tool is used to remove the bearings of primary
driven gear.
Cup-B
YSST-620-B
This tool is used to remove the bearings of front
wheel (LH & RH).
Cup- C
YSST-620-C
This tool is used to remove the bearing of main ax-
le/ V-belt case cover / drive axle (LH) crankcase.
Cup- D
YSST-620-D
This tool is used to remove the bearing of cam-
shaft.
Bearing puller 6001 & 6201
YSST-623
This tool is used to remove the bearing of cam-
shaft, main axle & primary driven gear.
Tool name/Tool No. Illustration
B7JF8197E1.book Page 7 Tuesday, June 29, 2021 2:28 PM
