TIGHTENING TORQUES
2-12
SPEC
EAS30017
CHASSIS TIGHTENING TORQUES
Item
Thread
size
Q’ty Tightening torque Remarks
Engine bracket and frame nut M10 2 50 N·m (5.0 kgf·m, 37 lb·ft)
Engine bracket and engine nut M10 1 54 N·m (5.4 kgf·m, 40 lb·ft)
Front fender and lower bracket bolt M6 3 12 N·m (1.2 kgf·m, 8.9 lb·ft)
Front fender bolt M6 2 6 N·m (0.6 kgf·m, 4.4 lb·ft)
Front wheel axle nut M12 1 26 N·m (2.6 kgf·m, 19 lb·ft)
Front brake cable holder (at lower
bracket)
M6 1 7 N·m (0.7 kgf·m, 5.2 lb·ft)
Front brake cable holder (LH front
fork)
M6 1 7 N·m (0.7 kgf·m, 5.2 lb·ft)
Front brake camshaft lever bolt M6 1 10 N·m (1.0 kgf·m, 7.4 lb·ft)
Horn bracket and lower bracket bolt M6 1 7 N·m (0.7 kgf·m, 5.2 lb·ft)
Steering lower and upper ring nut
M25
2 See TIP.
Lower bracket pinch bolt M10 4 53 N·m (5.3 kgf·m, 39 lb·ft)
Damper rod assembly bolt M8 2 23 N·m (2.3 kgf·m, 17 lb·ft)
Fuel pump assembly bolt M5 4 4 N·m (0.4 kgf·m, 3.0 lb·ft)
Tightening
in cross pat-
tern
Fuel tank bolt M6 4 7 N·m (0.7 kgf·m, 5.2 lb·ft)
Storage compartment bolt M6 4 9 N·m (0.9 kgf·m, 6.6 lb·ft)
Tightening
pattern
change now
anti-clock
wise.
Grab bar bolt M6 4 11 N·m (1.1 kgf·m, 8.1 lb·ft)
Fuel tank cover screw M5 2 1.8 N·m (0.18 kgf·m, 1.3 lb·ft)
Side cover screw M5 4 1.8 N·m (0.18 kgf·m, 1.3 lb·ft)
Rear reflector nut M5 1 1.5 N·m (0.15 kgf·m, 1.1 lb·ft)
Rear side reflector nut M5 2 1.5 N·m (0.15 kgf·m, 1.1 lb·ft)
Rear side reflector bracket bolt M6 2 3.8 N·m (0.38 kgf·m, 2.8 lb·ft)
Rear fender bolt M6 4 12 N·m (1.2 kgf·m, 8.9 lb·ft)
Tail light cover screw M5 4 1.8 N·m (0.18 kgf·m, 1.3 lb·ft)
Tail light assembly bolt M6 2 12 N·m (1.2 kgf·m, 8.9 lb·ft)
Tail light assembly screw M5 4 1.8 N·m (0.18 kgf·m, 1.3 lb·ft)
Under cover assembly bolt M6 2 12 N·m (1.2 kgf·m, 8.9 lb·ft)
Under cover assembly screw M5 6 1.8 N·m (0.18 kgf·m, 1.3 lb·ft)
Rear upper cover screw M5 2 1.8 N·m (0.18 kgf·m, 1.3 lb·ft)
Wire harness ground lead bolt (at
crank case)
M6 1 7 N·m (0.7 kgf·m, 5.2 lb·ft)
Center cover screw M5 2 1.8 N·m (0.18 kgf·m, 1.3 lb·ft)
Canister assembly bolt M6 1 9 N·m (0.9 kgf·m, 6.6 lb·ft)
Throttle cable holding bracket bolt (on
throttle body)
M6 1 7 N·m (0.7 kgf·m, 5.2 lb·ft)
LS
LT
