TIGHTENING TORQUES
2-13
SPEC
Ignition coil assembly bolt M6 2 7 N·m (0.7 kgf·m, 5.2 lb·ft)
Seat lock cable screw (at main switch) M5 1 1.8 N·m (0.18 kgf·m, 1.3 lb·ft)
SGCU (starter generator control unit)
assembly bolt
M6 2 9 N·m (0.9 kgf·m, 6.6 lb·ft)
Main switch bolt M6 2 7 N·m (0.7 kgf·m, 5.2 lb·ft)
Main switch cap screw - 1 2.8 N·m (0.28 kgf·m, 2.1 lb·ft)
Retractable hook bolt M6 1 10 N·m (1.0 kgf·m, 7.4 lb·ft)
Leg shield assembly bolt (LH & RH)
M6 2 7 N·m (0.7 kgf·m, 5.2 lb·ft)
Tip : This
bolt shall be
tightened
after
tightening
leg shield
Leg shield stay bolt M6 2 7 N·m (0.7 kgf·m, 5.2 lb·ft)
Leg shield assembly screw (LH & RH) M5 6 1.8 N·m (0.18 kgf·m, 1.3 lb·ft)
License plate stay nut M6 2 3.8 N·m (0.38 kgf·m, 2.8 lb·ft)
Rear leg shield screw M5 6 1.8 N·m (0.18 kgf·m, 1.3 lb·ft)
Leg shield screw (LH & RH) (tighten-
ing each other)
M5 1 1.8 N·m (0.18 kgf·m, 1.3 lb·ft)
Inner cover screw M5 6 1.8 N·m (0.18 kgf·m, 1.3 lb·ft)
Front turn signal light assembly screw
(LH/RH)
M5 6 1.8 N·m (0.18 kgf·m, 1.3 lb·ft)
Battery box cover screw (footrest
board side)
M5 2 1.8 N·m (0.18 kgf·m, 1.3 lb·ft)
Footrest board bolt M6 4 9 N·m (0.9 kgf·m, 6.6 lb·ft)
Leg shield screw (lower) M5 5 1.8 N·m (0.18 kgf·m, 1.3 lb·ft)
Battery cover bolt M6 1 4 N·m (0.40 kgf·m, 3.0 lb·ft)
Rear view mirror nut M10 2 23 N·m (2.3 kgf·m, 17 lb·ft)
Brake lever holder bolt (front and rear)
(drum)
M6 2 10 N·m (1.0 kgf·m, 7.4 lb·ft)
Throttle cable housing screw M5 2 1.4 N·m (0.14 kgf·m, 1.0 lb·ft)
Throttle cable plate and throttle cable
housing screw
M5 1 1.4 N·m (0.14 kgf·m, 1.0 lb·ft)
Throttle cable free play adjusting lock
nut
M6 1 3.8 N·m (0.38 kgf·m, 2.8 lb·ft)
Speedometer assembly screw M5 3 1.8 N·m (0.18 kgf·m, 1.3 lb·ft)
Handlebar cover screw (rear) M5 6 1.8 N·m (0.18 kgf·m, 1.3 lb·ft)
Handlebar cover screw (front) M5 2 1.8 N·m (0.18 kgf·m, 1.3 lb·ft)
Headlight beam adjusting bolt M6 1 2.5 N·m (0.25 kgf·m, 1.8 lb·ft)
Handlebar nut M10 1 53 N·m (5.3 kgf·m, 39 lb·ft)
Rear shock absorber upper bolt M8 1 25 N·m (2.5 kgf·m, 18 lb·ft)
Rear shock absorber lower bolt M8 1 25 N·m (2.5 kgf·m, 18 lb·ft)
Centerstand spring hook bolt M6 1 7 N·m (0.7 kgf·m, 5.2 lb·ft)
Sidestand nut
M10
1 32 N·m (3.2 kgf·m, 24 lb·ft)
Sidestand bolt
M10
1 12 N·m (1.2 kgf·m, 8.9 lb·ft)
Sidestand switch bolt M6 1 7 N·m (0.7 kgf·m, 5.2 lb·ft)
Rear brake cable holder bolt (at crank-
case)
M6 2 7 N·m (0.7 kgf·m, 5.2 lb·ft)
Item
Thread
size
Q’ty Tightening torque Remarks
LS
LT
