LUBRICATION POINTS AND LUBRICANT TYPES
2-15
SPEC
EAS20299
LUBRICATION POINTS AND LUBRICANT TYPES
EAS1MC1085
ENGINE
Lubrication point Lubricant
Bearings
O-rings
O-rings (camshaft)
Oil seal lips
Cylinder head nut (contact surface of nuts) and stud bolt thread part
Connecting rod big end thrust surface
Piston pin and connecting rod small end
Piston, piston ring, and cylinder inner surface
Crank shaft drive gear
Rocker arm shaft
Camshaft lobes
Camshaft flange (press fit part)
Valve stems (intake and exhaust)
Valve stem end (intake and exhaust)
Valve stem seals (intake and exhaust)
Decompression cam
Decompression lever
Cam chain sprocket bolt
Oil pump shaft outside surface
Throttle body joint O-ring
O-ring (fuel injector)
Kickstarter pinion gear shaft
Kick torsion spring
Drive axle and bearing (contact surface)
Primary shave nut and conical washer
Timing chain tensioner bolts Yamaha bond No.1215®
Crankcase mating surfaces Yamaha bond No.1215®
Crankcase (oil pump cover bolt) Yamaha bond No.1215®
E
LS
M
LS
M
E
E
E
M
M
M
E
M
M
E
M
M
M
E
LS
E
M
LS
LS
LS
