ELECTRICAL SPECIFICATIONS
2-7
SPEC
ELECTRICAL SPECIFICATIONS
Voltage
System voltage 12 V
Engine control unit
Model B7J1 (For disc)
B7J2 (For drum)
Ignition system
Ignition timing (B.T.D.C.) 3.0–7.0 °/1300 r/min
Ignition coil
Primary coil resistance 2.34–2.86 k
Secondary coil resistance 9.45–11.55 k
Spark plug cap
Resistance 4.00–6.00 k
Charging system
Charging system Starter generator
Standard output 13.0 V, 33.8 A at 5000 r/min
Stator coil resistance 0.039–0.059 
Rectifier/regulator
Regulated voltage (DC) 14.3–14.7 V
Battery
Model YTZ6V
Voltage, capacity 12 V, 5.0 Ah (10 HR)
Headlight
Bulb type Halogen bulb (For drum)
LED (For disc)
Bulb wattage
Headlight HS1, 35.0 W/35.0 W (For drum)
LED (For disc)
Brake/tail light 21.0 W/5.0 W (For drum)
LED (For disc)
Front turn signal light 10.0 W
Rear turn signal light 10.0 W
Auxiliary light 3.0 W (For drum)
Auxiliary light (DRL) LED (For disc)
Meter lighting LED
Indicator light
High beam indicator light LED
Turn signal indicator light LED
Engine trouble warning light LED
ECO indicator light LED
Stop and Start System indicator light LED
Acceleration assist indicator light LED
