CHASSIS SPECIFICATIONS
2-6
Front brake (Disc)
Brake disc thickness limit 3.0 mm (0.12 in)
Brake disc runout limit (as measured on wheel) 0.15 mm (0.0059 in)
Brake pad lining thickness limit 1.0 mm (0.04 in)
Master cylinder inside diameter 11.00 mm (0.43 in)
Caliper cylinder inside diameter (Right) 34.00 mm (1.34 in)
Specified brake fluid DOT 4
Brake cable UBS free play 0–1 mm
Rear brake
Type Mechanical leading trailing drum brake
Rear brake lever free play 10.0–15.0 mm (0.39–0.59 in) (for drum)
10.0–20.0 mm (0.39–0.79 in) (for disc)
Brake drum inside diameter limit 131.0 mm (5.16 in)
Lining thickness limit 2.0 mm (0.08 in)
Front suspension
Shock absorber Hydraulic damper
Fork spring free length (limit) 248.1 mm (9.77 in)
Inner tube bending limit 0.2 mm (0.01 in)
Recommended oil Yamaha Suspension Oil G10
Quantity (left) 54.0 cm³ (1.83 US oz, 1.90 Imp.oz)
Quantity (right) 54.0 cm³ (1.83 US oz, 1.90 Imp.oz)
Level (left) 85 mm (3.3 in)
Level (right) 85 mm (3.3 in)
Rear suspension
Shock absorber Hydraulic damper
