ELECTRICAL SPECIFICATIONS
2-8
Fuel sender unit
Sender unit resistance (full) 4.0–10.0
Sender unit resistance (empty) 90.0–100.0
Fuel injection sensor
Crankshaft position sensor resistance 217–325
Intake air temperature sensor resistance 5700–6300 at 0 °C (5700–6300 at 32 °F)
Atmospheric pressure sensor output voltage 3.88–4.12 V at 101.3 kPa
(3.88–4.12 V at 1.01 kgf/cm², 3.88-4.12 V at
14.7 psi)
Engine temperature sensor resistance 2513-2777 at 20 °C (2513-2777 at 68 °F)
Engine temperature sensor resistance 210–221 at 100 °C (210–221 at 212 °F)
Fuse(s)
Main fuse 15.0 A
Sub fuse 7.5 A
Terminal fuse 1 2.0 A
Backup fuse 2.0 A
Sub fuse 2 7.5 A
