Yamaha MAJESTY YP400A - Replacing a Rear Turn Signal Light Bulb

PERIODIC MAINTENANCE AND ADJUSTMENT
7-35
1
2
3
4
5
6
7
8
9
5. Remove the socket (together with
the bulb) by turning it counter-
clockwise.
6. Remove the burnt-out bulb by
pushing it in and turning it counter-
clockwise.
7. Insert a new bulb into the socket,
push it in, and then turn it clock-
wise until it stops.
8. Install the socket (together with the
bulb) by turning it clockwise.
9. Place the turn signal light unit in
the original position, and then in-
stall the screws.
10. Install the windshield by installing
the screws.
11. Install panel A.
EAU34263
Replacing a rear turn signal
light bulb
1. Place the scooter on the center-
stand.
2. Remove cowling C for replacing
the left turn signal light bulb or
cowling D for replacing the right
turn signal light bulb. (See
page 7-8.)
3. Remove the socket (together with
the turn signal light bulb) by turning
it counterclockwise.
4. Remove the burnt-out bulb by
pushing it in and turning it counter-
clockwise.
5. Insert a new bulb into the socket,
1. Screw
2. Front turn signal light unit
1. Turn signal light bulb socket
1
2
1
1. Turn signal light bulb socket
1
✼✦✧✯✪✥✲✣ ✦  
