PERIODIC MAINTENANCE AND ADJUSTMENT
7-34
2
3
4
5
6
7
8
9
EAU34240
Replacing a headlight bulb
This model is equipped with quartz bulb
headlights. If a headlight bulb burns
out, have a Yamaha dealer replace it
and, if necessary, adjust the headlight
beam.
EAU24181
Tail/brake light
This model is equipped with an
LED-type tail/brake light.
If the tail/brake light does not come on,
have a Yamaha dealer check it.
EAU36124
Replacing a front turn signal
light bulb
1. Place the scooter on the center-
stand.
2. Remove panel A. (See page 7-8.)
3. Remove the windshield by remov-
ing the screws.
4. Remove the front turn signal light
unit by removing the screws.
1. Screw
2. Windshield
✼✦✧✯✪✥✲✣ ✦✧
