PERIODIC MAINTENANCE AND ADJUSTMENT
7-36
2
3
4
5
6
7
8
9
push it in, and then turn it clock-
wise until it stops.
6. Install the socket (together with the
bulb) by turning it clockwise.
7. Install the cowling removed.
EAU34273
Replacing the license plate
light bulb
1. Place the scooter on the center-
stand.
2. Remove cowling B. (See
page 7-8.)
3. Remove the license plate light cov-
er and license plate light lens by
removing the screws.
4. Remove the burnt-out bulb by
pushing it in and turning it counter-
clockwise.
5. Insert a new bulb into the socket,
push it in, and then turn it clock-
wise until it stops.
6. Install the license plate light lens
and license plate light cover by in-
stalling the screws.
7. Install the cowling.
1. License plate light lens
2. License plate light cover
3. Screw
1
2
3
1. Bulb
✼✦✧✯✪✥✲✣ ✦✩
