3
DC IN
POWER
ON/
OFF
Power Supply
Use the PA-3B power adaptor (or another adaptor recommended by Yamaha) to supply
the MFC10 with power from a convenient wall socket.
2
Plug the AC adaptor into any convenient AC wall
socket.
1
Connect the adaptor’s plug into the [DC IN] jack on the
rear panel.
Wrap the power cord around the cord stopper hook to
prevent accidental unplugging during use.
Cord Stopper
Wall Socket
Power Adaptor
• Do not use an AC adaptor other than the
PA-3B, or other adoptors recommended by
Yamaha. The use of any incompatible adaptor
may result in damage, overheating, or fire to
the unit.
• Be sure to disconnected the power adaptor
from the outlet when the MFC10 is not in use.
