Yamaha MOTIF XS6 Service Manual

106
MOTIF XS6/MOTIF XS7/MOTIF XS8
X
X'
to PNA-CN1
PNC-CN1
REMOTE
ON/OFF
ARPEGGIO
ON/OFF
EFFECT BYPASS
INSERTION
OCTAVE DOWN
EFFECT BYPASS
SYSTEM
OCTAVE UP
MASTER EFFECT
!
(TOP)! (TOP)

(REC) (REC)

(REW) (REW)

(STOP) (STOP)

(FF) (FF)
#
(PLAY)# (PLAY)
SELECTED/MULTI PART CTRL5
SELECTED/
MULTI PART CTRL6
SELECTED/
MULTI PART CTRL7
SELECTED/
MULTI PART CTRL8
VOLUME 5 VOLUME 6 VOLUME 7 VOLUME 8
PNB-PN Circuit Board
2NA-WG45440
1
Scale: 90/100

Yamaha MOTIF XS6 Specifications

General

Polyphony	128 notes
Wave ROM	355MB (when converted to 16-bit linear format)
Type	Workstation Synthesizer
Keyboard	61 keys
Voices	1, 024 normal voices + 64 drum kits
Effects	Reverb x 9 types, Chorus x 22 types
Sequencer	16 tracks
Display	320 x 240 dot, backlit LCD
Connectors	MIDI IN/OUT/THRU, USB TO HOST, USB TO DEVICE
Storage	USB storage device
