MOTIF XS6/MOTIF XS7/MOTIF XS8
130
[Judgment indication]
No indication
[MIDI code output for judgment result]
None
[How to quit test]
• MANUAL MODE:
Press the [EXIT] button and sound will stop playing and a
condition waiting for test number will be selected.
• MIDI MODE:
Send a test code for another test to complete the current test
and the test for the newly sent test code will be executed.
[Others]
None
T18: DIMM
(Test Code: A01900)
[First indication]
[Test contents]
Executes Write/Read/Verify test of the DIMM.
Through the SWP51 (Master side (DM: IC010)), specific
data are written to the specifi ed address group of the DIMM
and the data are loaded and compared with the written data.
[Test method]
Executes the test.
[Check item]
Check the test result on the LCD.
Press
[ENTER]
18 :
DIMM
TEST
MOTIF XS Test Program
[Judgment indication]
OK
xxxxxxxx: Capacity
18 :
DIMM
TEST
MOTIF XS Test Program
OK
Memory Size xxxxxxxx Byte
Example of an NG
xxxxxxxx: Capacity
18 :
DIMM
TEST
MOTIF XS Test Program
NG
Memory Size xxxxxxxx Byte
If any IC is NG the result will be NG.
[MIDI code output for judgment result]
OK: A0 19 02 <==
NG: A0 19 03 <==
[How to quit test]
When the judgment is shown and output, the test will be
completed and item selection condition will be selected.
[Others]
None
