5
MOTIF XS6/MOTIF XS7/MOTIF XS8
Others
Master User: 128
*8 Zones (Master keyboard settings), Assignable Knob/Slider settings, Program Change Table
Sequence Software
compatible with the
Remote Control
function
For Windows
®
: Cubase 4, SONAR 5.2
For Macintosh
®
: Cubase 4, Logic 7.2, Digital Performer 5.1
*Functions to be controlled differ depending on the software.
Controllers Pitch Bend wheel, Modulation wheel, Ribbon Controller, Assignable Control Sliders x 8,
Assignable Knobs x 8, Assignable Function buttons x 2, Data dial
Display 320 x 240 dot, 5.7 inch graphic color backlit LCD
Connectors OUTPUT L/MONO, R (standard phone jack)
ASSIGNABLE OUTPUT L, R (standard phone jack)
A/D INPUT L, R (standard phone jack)
DIGITAL OUT
PHONES (standard stereo phone jack)
FOOT CONTROLLER 1, 2
FOOT SWITCH x 2 (SUSTAIN, ASSIGNABLE)
MIDI IN/OUT/THRU
USB (TO HOST, TO DEVICE)
AC IN
ETHERNET
mLAN (MOTIF XS8 only)
Power Consumption 30 W
Dimensions, Weight MOTIF XS8: 1,457 (W) x 466 (D) x 168 (H) mm, 28.6 kg
MOTIF XS7: 1,252 (W) x 391 (D) x 122 (H) mm, 17.0 kg
MOTIF XS6: 1,045 (W) x 391 (D) x 122 (H) mm, 14.8 kg
Accessories AC Power cord, Media (disc) x 1, Owner’s Manual, Data List

Yamaha MOTIF XS6 Specifications

General

Polyphony	128 notes
Wave ROM	355MB (when converted to 16-bit linear format)
Type	Workstation Synthesizer
Keyboard	61 keys
Voices	1, 024 normal voices + 64 drum kits
Effects	Reverb x 9 types, Chorus x 22 types
Sequencer	16 tracks
Display	320 x 240 dot, backlit LCD
Connectors	MIDI IN/OUT/THRU, USB TO HOST, USB TO DEVICE
Storage	USB storage device
