1
English
CONTENTS
FEATURES................................................................................................................................................................................ 1
CONTROLS AND FUNCTIONS .............................................................................................................................................2
CONNECTIONS ....................................................................................................................................................................... 4
BLOCK DIAGRAMS................................................................................................................................................................ 6
TROUBLESHOOTING............................................................................................................................................................. 8
SPECIFICATIONS ................................................................................................................................................................... 9
• 500 W + 500 W max. (4 to 8 Ω) high-power, high-performance digital stereo power amplifier
• 120 dB dynamic range
• Yamaha-designed LSI chips used in the digital-modulation and power-drive circuits
• Active Power Control System ensures optimum performance under any load
• Constant Gain PLL Modulator provides a fixed open-loop gain that is unaffected by supply voltage fluctuations
• 0.003% THD (Total Harmonic Distortion)
• 100 dB channel separation
• Yamaha’s own high-efficiency, low-noise resonant-type switching power supply
• WBT (German) connectors used for inputs (RCA) and speaker outputs
• Futuristic, super-thin design
Accessories
Power cable
Clamp filter (for power cable) x 2
Fixing tie x 2
Clamp filter (for audio pin cable)
(U.S.A. and Canada models)
Clamp filter (for RS-232C interface cable)
Clamp filter (for control cable) x 2
(U.S.A. and Canada models)
Be sure to attach the clamp filters to the corresponding cables in order to reduce the electromagnetic interference.
Open the cover and fit the core onto the cables.
FEATURES
