Periodic maintenance and adjustment
6-16
6
9. Remove the coolant reservoir cap,
and then turn the coolant reservoir
upside down to empty it.
10. After the coolant is completely
drained, thoroughly flush the cool-
ing system with clean tap water.
11. Install the coolant reservoir by in-
stalling the bolt.
12. Install the coolant drain bolt and
its new gasket, and then tighten
the bolt to the specified torque.
13. Install the coolant drain screw and
its new O-ring.
14. Pour the recommended coolant
into the reservoir to the maximum
level mark, and then install the
coolant reservoir cap.
15. Pour the recommended coolant
into the radiator until it is full.
16. Install the radiator cap, start the
engine, let it idle for several min-
utes, and then turn it off.
17. Remove the radiator cap to check
the coolant level in the radiator. If
necessary, add sufficient coolant
until it reaches the top of the radi-
ator, and then install the radiator
cap.
18. Start the engine, and then check
the vehicle for coolant leakage. If
coolant is leaking, have a Yamaha
dealer check the cooling system.
19. Install the radiator cover by install-
ing the bolts.
20. Install the panels.
Tightening torque:
Coolant drain bolt:
10 N·m (1.0 kgf·m, 7.2 lb·ft)
Antifreeze/water mixture ratio:
1:1
Recommended antifreeze:
High-quality ethylene glycol anti-
freeze containing corrosion inhibi-
tors for aluminum engines
Coolant quantity:
Radiator (including all routes):
0.46 L (0.49 US qt, 0.40 Imp.qt)
Coolant reservoir (up to the maxi-
mum level mark):
0.25 L (0.26 US qt, 0.22 Imp.qt)
