4 En
3
Connect the surround speakers ( /
) to the SURROUND ( / )
terminals.
4
Connect the subwoofer ( ) to the
SUBWOOFER (1) jack.
Use an audio pin cable to
connect the subwoofer
().
Connect the surround back speakers ( /
) to the SURROUND BACK ( / )
terminals.
This unit (rear)
This unit (rear)
For 7.1-channel system
This unit (rear)
Audio pin cable
