Instrument and control functions
4-10
4
EAU12892
Brake lever
The brake lever is located on the right
side of the handlebar. To apply the
front brake, pull the lever toward the
throttle grip.
EAU12944
Brake pedal
The brake pedal is located on the right
side of the motorcycle. To apply the
rear brake, press down on the brake
pedal.
EAU37474
Fuel tank cap
To remove the fuel tank cap
1. Open the seat. (See page 4-12.)
2. Turn the fuel tank cap counter-
clockwise and pull it off.
To install the fuel tank cap
1. Insert the fuel tank cap into the
tank opening and turn it clockwise
until the “ ” marks on the cap
and tank cover are aligned.
2. Close the seat.
1. Brake lever
1
1. Brake pedal
1
1. Fuel tank cap
2. “ ” mark
1
2
