Periodic maintenance and adjustment
7-33
7
6. Install the socket (together with
the bulb) by turning it clockwise.
7. Install the panels.
EAUV0960
Replacing a rear turn signal
light bulb
1. Remove the turn signal light unit
by removing the screw.
2. Remove the socket (together with
the turn signal light bulb) by turn-
ing it counterclockwise.
3. Remove the burnt-out bulb by
pulling it outward.
4. Insert a new bulb into the socket.
5. Install the socket (together with
the bulb) by turning it clockwise.
6. Install the turn signal light unit by
installing the screw. NOTICE: Do
not overtighten the screw, oth-
erwise the lens may break.
[ECA11192]
1. Screw
1. Turn signal light bulb
