Yamaha WaveRunner XL700 Service Manual

45
IGNITION SYSTEM
ELEC
NOTE:
  BBr/WO P W W/R
B 2 – 6  3 – 11 10 – 40 150 – 600
Br/W 20 – 80  50 – 200 15 – 60
250 – 1000
O   
P ∞∞∞ ∞ ∞
W ∞∞∞∞ ∞
W/R 9 – 36 17 – 70  10 – 40 50 – 200
Unit: kΩ
CDI UNIT
1. Measure:
 CDI unit resistance
Out of specification  Replace.
Pocket tester:
YU-03112/90890-03112
 The resistance values will vary from meter to
meter, especially with electronic digital meters.
For some testers, the polarity of the leads is re-
versed.
 The needle swings once to the “” mark and
then returns to the home position.
 The “∞” mark stands for discontinuity.
B : Black
Br/w : Brown/white
O : Orange
P : Pink
W : White
W/R : White/Red

Yamaha WaveRunner XL700 Specifications

General

Manufacturer	Yamaha
Model	WaveRunner XL700
Category	Boat
Engine Type	2-cylinder, 2-stroke
Displacement	701cc
Fuel Capacity	13.2 gallons
Oil Capacity	3.2 quarts
Compression Ratio	7.2:1
Starter System	Electric
Lubrication System	Oil injection
Cooling System	Water-cooled
Seating Capacity	3 persons
Bore x Stroke	81mm x 68mm
Fuel Delivery	Mikuni carburetor
