Yamaha WaveRunner XL700 Service Manual

22
EXHAUST RING
POWR
Step Procedure/Part name Q’ty Service points
1
2
3
4
5
6
7
8
9
EXHAUST RING REMOVAL
Pilot water hose
Clamp
Exhaust joint
Clamp
Bolt (with washer)
Ring assembly
Clamp
Joint
Exhaust joint
1
2
1
1
4
1
1
1
1
Follow the left “Step” for removal.
 Pull and side the exhaust joint.
 Loosen the clamp on the chamber side.
Tighten the clamp before installing the
ring on the muffler.
Reverse the removal steps for
installation.
NOTE:
2 Nm (0.2 mkg, 1.4 ftlb)
2 Nm (0.2 mkg, 1.4 ftlb)
30 Nm (3.0 mkg, 22 ftlb)
CAUTION:
EXHAUST RING
EXPLODED DIAGRAM
REMOVAL AND INSTALLATION CHART

Yamaha WaveRunner XL700 Specifications

General

Manufacturer	Yamaha
Model	WaveRunner XL700
Category	Boat
Engine Type	2-cylinder, 2-stroke
Displacement	701cc
Fuel Capacity	13.2 gallons
Oil Capacity	3.2 quarts
Compression Ratio	7.2:1
Starter System	Electric
Lubrication System	Oil injection
Cooling System	Water-cooled
Seating Capacity	3 persons
Bore x Stroke	81mm x 68mm
Fuel Delivery	Mikuni carburetor
