8-24
8
4. Install the differential gear oil drain bolt
and its new gasket, and then tighten the
bolt to the specified torque.
5. Refill the differential gear case with the
recommended oil.
GL-4 is a quality and additive rating; GL-5
rated hypoid gear oils may also be used.
If desired, an SAE 80W-90 hypoid gear oil
may be used instead.
6. Check the oil filler bolt gasket for dam-
age, and replace it if necessary.
7. Install the differential gear oil filler bolt
and its gasket, and then tighten the bolt
to the specified torque.
8. Check for oil leakage. If oil leakage is
found, check for the cause.
1. Differential gear oil drain bolt
2. Gasket
Tightening torque:
Differential gear oil drain bolt:
9.8 N·m (0.98 kgf·m, 7.2 lb·ft)
Tightening torque:
Differential gear oil filler bolt:
23 N·m (2.3 kgf·m, 17 lb·ft)
UB3D7AE0.book Page 24 Tuesday, November 7, 2017 9:38 AM
